New 16 channel 3G(UMTS) Madcom

Print
The newest device
madcom16x16
madcom16x16
Main characteristics
SKU 2082
Vendor Madcom
Category Medium enterprises
Standart 3G/900/2100 - VoIP/SIP/H323
Power source 12V
SMS(MMS) sms server, ussd
Antenna 16 (SMA-female)
Memory RAM 16MB/ Flash 4MB
Q'ty of channels 16 UMTS
Q'ty SIM per channel 1
Interface Lan, PC, USB
Management WEB
IMEI changing Yes
Dimensions, HWD 250 õ 223 õ 40 mm
Weight 1.55 kg
Shipment Worldwide
Price 2299 $
Other currency 2103 ˆ
Delivery 7 days
Wire Transfer VISA MasterCard PayPal
Product introduction:

Madcom is a professional developer and manufacturer of VoIP products. Madcom provide new brand VoIP communication devices and solutions. And we also offer customized products and OEM service. They are a cost-effective gateway for SOHO, SMEs and system integrators and it also opens up new revenue generating opportunities for service providers.

Madcom - 16/16 series is able to process traditional voice call service and internet data service. Compare to the Madcom - 16/16 series VoIP Gateway, Madcom - 16/16 series adapt new hardware and software structure, which supports up to 16 concurrent calls.

Special Features:

Support G729a/b/e,G723.1,G.711 A/U law, iLBC auto-selecting
Proxy Encryption Solution for IP Block
Support SIM Bank
VPN(pptp)
SIM Card Rotating(64) Optional
        Solution to solve the SIM card blocked by:
              Accumulated Call Duration
              Accumulated Connected Calls
              Accumulated Calls
              Consecutive Failed Calls
              Consecutive No-Alert Calls
              Consecutive No-Answer Calls
              Consecutive No Carrier Calls
              Consecutive Short-Duration Calls
Station intelligent switching
(Remote Management System)
Port Inter-Calling
Fake Ringback
Call Duration Limitation for SIM Card/Single
Dial Plan/Prefix Inward Translation/Intelligent Routing
Web Browser: Firefox/Chrome /IE/Opera

File Title Release Date File Type Size (mb) Action
User's Guide to the GSM / UMTS gateway series Madcom 12-25-2014 Documentation (pdf) 1.09 MB download

To access this product file, get partner STE status


Mobile Features:


SMS Send, Receive and Forward(GSM/SIP/HTTP) SMS Inbox AT Command , USSD SMS Format: PDU/TXT PIN Code Management GSM Polarity Reversal Carrier Selection Caller ID Hidden(need SIM Card support)

Maintenance and Management

Multi-language Interface USB Serial COM Configuration Backup and Restore Support HTTP/TFTP Upgrade Call statistics: ASR,ACD,PDD Remote Management System

File Title Release Date File Type Size (mb) Action
User's Guide to the GSM / UMTS gateway series Madcom 12-25-2014 Documentation (pdf) 1.09 MB download

To access this product file, get partner STE status


Model

Madcom 16/16

Number of Channels

16 channels

Frequency

UMTS: 2100 MHz

SIP Specification

·SIP/2.0 RFC3261
·Session Timer RFC4028
·STUN

Network Protocols

•DHCP/PPPoE/VPN(pptp)
•NTP
•Telnet/HTTP/FTP/TFTP
•Encryption:Ejoin,VOS2000,RC4,XOP.Base64

Telephony Features

Hot-line call ,Dial plan, Speed dial, Phone book, CDR, LCR, White/Black list

Telephony Signaling

·DTMF tone dectection/generation
·DTMF relay: in-band, RFC 2833 and SIP info
·Call forward: unconditional, no answer and busy
·N-way conferencing
·Caller ID display/generation, Mobile Number Portability

Voice Capability

·Voice codecs:G729a/b/e,G723.1,G.711 A/U law, iLBC
·Echo cancellation
·Silence suppression & detection(VAD, CNG)
·Adaptive jitter buffer
·Volume adjustable
·IVR customized

Number of Ports

·1 WAN 10/100Base-T ethernet(RJ-45 connector)
·1 LAN 10/100Base-T ethernet(RJ-45 connector)
·1 Console(USB)

LEDs

1 Power and 16 groups of card online and running status indicator

Power Supply

100-240VAC, 50 - 60 Hz IN, 12V/5A OUT

Operating Environment

•Operating temperature: 0 - 50ºC
•Operating humidity: 10 – 90%RH

Warranty

12 months

File Title Release Date File Type Size (mb) Action
User's Guide to the GSM / UMTS gateway series Madcom 12-25-2014 Documentation (pdf) 1.09 MB download

To access this product file, get partner STE status

File Title Release Date File Type Size (mb) Action
User's Guide to the GSM / UMTS gateway series Madcom 12-25-2014 Documentation (pdf) 1.09 MB download

To access this product file, get partner STE status

Additional Product Information
IMEI changing
Embedded 64 sim bank
